1995 FAMUP MCX 600
1995 FAMUP MCX 600
or
Call 330388720247
Description
CNC SIEMENS 810 Machine can be inspect under power. Origin: Italy
Specifications
| Manufacturer | FAMUP |
| Model | MCX 600 |
| Year | 1995 |
| Condition | Used |
| Stock Number | 1105-03112 |
| Controls | CNC, SIEMENS 810 D |
| Country of origin | italy |
| Delivery time | immediately |
| Delivery terms | EXW 'as is where is' |
| X-travel | 600 mm |
| Y-travel | 400 mm |
| Z-travel | 400 mm |
| X-axis traverse | 600 mm |
| Y-axis traverse | 400 mm |
| Z-axis traverse | 400 mm |
| Number of controlled axes | 3 |
| Table surface (left-right) | 400 mm |
| Table surface (front-back) | 400 mm |
| Workpiece load (max) | 300 kg |
| Spindle revolutions (max) | 6000 /min |
| Tool fixture | ISO SK 40 |
| Drive power (max) | 11 kW |
| Number of positions | 18 |
| Tool diameter max. | 75 mm |
| Tool changing time | 2 s |
| Space requirements length | 3200 mm |
| Space requirements width | 2.900 mm |
| Total height | 2600 mm |
| Total weight approx. | 3500 kg |
