2003 HERMLE C 600 U
No longer available
2003 HERMLE C 600 U
Description
5 Axis CNC - Machining Center Universal HERMLE - C 600 U TNC HEIDENHAIN 530 CHIP CONVOYER HEIDENHAIN PROBE 16000 RM MAGASIN 30 POSITIONS
Specifications
| Manufacturer | HERMLE |
| Model | C 600 U |
| Year | 2003 |
| Condition | Used |
| Stock Number | 1105-03677 |
| Controls | CNC, TNC 530 Heidenhain |
| Country of origin | Germany |
| Delivery time | CALL ME |
| Delivery terms | ex site |
| X-travel | 600 mm |
| Y-travel | 450 mm |
| Z-travel | 450 mm |
| Turning speed range - main spindle | 16000 min/-1 |
| Power capacity - main spindel | 7 / 9 kW |
| Tool taper | SK 40 |
| Spindle bearing diameter | 70 mm |
| Measuring system | direct |
| Resolution | 0,001 mm |
| Table surface area | Ø 280 mm |
| Max. table load | 250 kg |
| Swivel range | +/- 110 ° |
| Rotatable | 360000 ° |
| Number of toolpositions | 30 pos. |
| Max. tool diameter | 80 (125) mm |
| Change-time chip to chip | 5,5 sec |
| Rapid traverse ( x / y / z ) | 35 / 35 / 35 m/min |
| Feed speeds | 1 - 30.000 mm/min |
| Feed force | 6 kN |
| Total power requirement | 30 kVA |
| Weight of the machine ca. | 6,5 t |
| Dimensions of the machine ca. | 3,5 x 3,5 x 2,8 m |
| Automatic tool changer | 30 pos. |
