1996 MORI SEIKI SL 150

1996 MORI SEIKI SL 150

orCall 330388720247

Description

Machine-Details

Stock-No.1105-03860Type of machineCNC LatheMakeMORI SEIKI

TypeSL 150Year of manufacture1996

Type of controlCNCStorage locationLagerCountry of originJapanDelivery timeimmediatelyFreight basisex Warehouse, free on truck Price on request





Technical details

turning diameter420 mmcentre distance580 mmturning length max. 500 mm travel x / y230 / 520 mm spindle turning speed range50 - 5000 U/min spindle noseJIS A2-5bar diameter round max42 mm spindle bearing diameter90 mm tool turret - number of stations12 (12)tool taper20 x 20tailstock adjustment515 mm tailstock quill diameter85 mm tailstock quill taper MT4tailstock travel120 mm rapid travel - longitudinal/face24 / 18 m/min coolant tank160 l connected load21 kVA

weight of the machine ca.4,1 tdimensions of the machine ca.7,5 x 2,5 x 1,8 m

Fanuc CNC control 16T



tailstock C

hip conveyor


complete equipped with tools

CHIP CONVOYER


Specifications

ManufacturerMORI SEIKI
ModelSL 150
Year1996
ConditionUsed
